3 Phase Pumps

Online Catalogue | Mono Subrotor Borehole Pump |  3 Phase Pumps

SS0222103

SS0222103


Price: 973.00 (Excluding VAT at 20%)

20 Litres / min, 1.2m3/h, Max 150mtrs Head.


.75Kw/1.0Hp, 3Ph, 415V, 2.2Amps.

The Mono Subrotor pump offers the first real alternative to the muilt-stage centrifugal borehole pump. Unlike the conventional borehole pump which uses centrifugal force as the energy to move the water, the Mono Subrotor uses the Progressing Cavity Rotor/Stator principle to draw the water up.

When the hard chrome plated rotor fits inside the rubber stator the two components touch and form a seal bead, behind which a sealed capsule is formed, which moves from the suction side to the discharge of the pump as the rotor rotates inside the stator. The liquid within the capsule is delivered so positively that the pump is capable of very high pressure.
Applications: Suitable for 4" minimum boreholes, Can pump from rivers where surface pumps cannot be used, Waste water wier clearing, Leachate.

Easy to maintain.

Rotor/Stator self cleaning and ensures no algae or oxide deposits i.e. no clogged pump impellers.

SS0412103

SS0412103


Price: 973.00 (Excluding VAT at 20%)

40 Litres / min, 2.4m3/h, Max 75mtrs Head


75Kw/Hp, 3Ph, 415V, 2.2Amps.

The Mono Subrotor pump offers the first real alternative to the muilt-stage centrifugal borehole pump. Unlike the conventional borehole pump which uses centrifugal force as the energy to move the water, the Mono Subrotor uses the Progressing Cavity Rotor/Stator principle to draw the water up.

When the hard chrome plated rotor fits inside the rubber stator the two components touch and form a seal bead, behind which a sealed capsule is formed, which moves from the suction side to the discharge of the pump as the rotor rotates inside the stator. The liquid within the capsule is delivered so positively that the pump is capable of very high pressure.
Applications: Suitable for 4" minimum boreholes, Can pump from rivers where surface pumps cannot be used, Waste water wier clearing, Leachate.

Easy to maintain.

Rotor/Stator self cleaning and ensures no algae or oxide deposits i.e. no clogged pump impellers.

SS0422203

SS0422203


Price: 1,076.00 (Excluding VAT at 20%)

40 Litres / min, 2.4m3/h, Max 150mtrs Head


1.5Kw/2.0Hp, 3Ph, 415V, 3.9Amps.

The Mono Subrotor pump offers the first real alternative to the muilt-stage centrifugal borehole pump. Unlike the conventional borehole pump which uses centrifugal force as the energy to move the water, the Mono Subrotor uses the Progressing Cavity Rotor/Stator principle to draw the water up.

When the hard chrome plated rotor fits inside the rubber stator the two components touch and form a seal bead, behind which a sealed capsule is formed, which moves from the suction side to the discharge of the pump as the rotor rotates inside the stator. The liquid within the capsule is delivered so positively that the pump is capable of very high pressure.
Applications: Suitable for 4" minimum boreholes, Can pump from rivers where surface pumps cannot be used, Waste water wier clearing, Leachate.

Easy to maintain.

Rotor/Stator self cleaning and ensures no algae or oxide deposits i.e. no clogged pump impellers.

SS0612153

SS0612153


Price: 1,019.00 (Excluding VAT at 20%)

60 Litres / min, 3.6m3/h, Max 75mtrs Head

1.1Kw/1.5Hp, 3Ph, 415V, 3.2Amps.

The Mono Subrotor pump offers the first real alternative to the muilt-stage centrifugal borehole pump. Unlike the conventional borehole pump which uses centrifugal force as the energy to move the water, the Mono Subrotor uses the Progressing Cavity Rotor/Stator principle to draw the water up.

When the hard chrome plated rotor fits inside the rubber stator the two components touch and form a seal bead, behind which a sealed capsule is formed, which moves from the suction side to the discharge of the pump as the rotor rotates inside the stator. The liquid within the capsule is delivered so positively that the pump is capable of very high pressure.
Applications: Suitable for 4" minimum boreholes, Can pump from rivers where surface pumps cannot be used, Waste water wier clearing, Leachate.

Easy to maintain.

Rotor/Stator self cleaning and ensures no algae or oxide deposits i.e. no clogged pump impellers.

SS0622303

SS0622303


Price: 1,237.00 (Excluding VAT at 20%)

60 Litres / min, 3.6m3/h, Max 150mtrs Head

2.2Kw/3.0Hp, 3Ph, 415V, 5.3Amps.

The Mono Subrotor pump offers the first real alternative to the muilt-stage centrifugal borehole pump. Unlike the conventional borehole pump which uses centrifugal force as the energy to move the water, the Mono Subrotor uses the Progressing Cavity Rotor/Stator principle to draw the water up.

When the hard chrome plated rotor fits inside the rubber stator the two components touch and form a seal bead, behind which a sealed capsule is formed, which moves from the suction side to the discharge of the pump as the rotor rotates inside the stator. The liquid within the capsule is delivered so positively that the pump is capable of very high pressure.
Applications: Suitable for 4" minimum boreholes, Can pump from rivers where surface pumps cannot be used, Waste water wier clearing, Leachate.

Easy to maintain.

Rotor/Stator self cleaning and ensures no algae or oxide deposits i.e. no clogged pump impellers.

SS1012203

SS1012203


Price: 1,419.00 (Excluding VAT at 20%)

100 Litres / min, 5.8m3/h, Max 75mtrs Head

1.5Kw/2.0Hp, 3Ph, 415V, 3.9Amps.

The Mono Subrotor pump offers the first real alternative to the muilt-stage centrifugal borehole pump. Unlike the conventional borehole pump which uses centrifugal force as the energy to move the water, the Mono Subrotor uses the Progressing Cavity Rotor/Stator principle to draw the water up.

When the hard chrome plated rotor fits inside the rubber stator the two components touch and form a seal bead, behind which a sealed capsule is formed, which moves from the suction side to the discharge of the pump as the rotor rotates inside the stator. The liquid within the capsule is delivered so positively that the pump is capable of very high pressure.
Applications: Suitable for 4" minimum boreholes, Can pump from rivers where surface pumps cannot be used, Waste water wier clearing, Leachate.

Easy to maintain.

Rotor/Stator self cleaning and ensures no algae or oxide deposits i.e. no clogged pump impellers.

SS1022303

SS1022303


Price: 1,591.00 (Excluding VAT at 20%)




100 Litres / min, 5.8 m3/h, Max 125mtrs Head


2.2Kw/3.0Hp, 3Ph, 415V, 5.3Amps.

The Mono Subrotor pump offers the first real alternative to the muilt-stage centrifugal borehole pump. Unlike the conventional borehole pump which uses centrifugal force as the energy to move the water, the Mono Subrotor uses the Progressing Cavity Rotor/Stator principle to draw the water up.

When the hard chrome plated rotor fits inside the rubber stator the two components touch and form a seal bead, behind which a sealed capsule is formed, which moves from the suction side to the discharge of the pump as the rotor rotates inside the stator. The liquid within the capsule is delivered so positively that the pump is capable of very high pressure.
Applications: Suitable for 4" minimum boreholes, Can pump from rivers where surface pumps cannot be used, Waste water wier clearing, Leachate.

Easy to maintain.

Rotor/Stator self cleaning and ensures no algae or oxide deposits i.e. no clogged pump impellers.



SS1512303

SS1512303


Price: 1,705.00 (Excluding VAT at 20%)

150 Litres / min, 7.2m3/h, Max 75mtrs Head.


2.2Kw/3.0Hp, 3Ph, 415V, 5.3Amps.

The Mono Subrotor pump offers the first real alternative to the muilt-stage centrifugal borehole pump. Unlike the conventional borehole pump which uses centrifugal force as the energy to move the water, the Mono Subrotor uses the Progressing Cavity Rotor/Stator principle to draw the water up.

When the hard chrome plated rotor fits inside the rubber stator the two components touch and form a seal bead, behind which a sealed capsule is formed, which moves from the suction side to the discharge of the pump as the rotor rotates inside the stator. The liquid within the capsule is delivered so positively that the pump is capable of very high pressure.
Applications: Suitable for 4" minimum boreholes, Can pump from rivers where surface pumps cannot be used, Waste water wier clearing, Leachate.

Easy to maintain.

Rotor/Stator self cleaning and ensures no algae or oxide deposits i.e. no clogged pump impellers.
